* PowerLogic P1 Protection Relays
PowerLogic P1F – Feeder protection
REL15000 Ion = 1 A/5 A ; 0.01…2 Ion 24…240 Vac/250 Vdc; P1F1L1N0N92N0NN11N
REL15001 Ion = 1 A/5 A ; 0.05…12Ion 24…240Vac/250Vdc; P1F1L1N3N92N0NN11N
REL15002 Ion = 1 A/5 A ; 0.01…2 Ion 24…240 Vac/250Vdc; P1F1L1N0N92N1NN11N
REL15003 Ion = 1 A/5 A ; 0.05…12 Ion 24…240 Vac/250Vdc; P1F1L1N3N92N1NN11N
REL15004 Ion = 1 A/5 A ; 0.01…2 Ion 24…240 Vac/250 Vdc; P1F1N1N0N92N1NN11N
REL15005 Ion = 1 A/5 A ; 0.05…12 Ion 24…240 Vac/250 Vdc; P1F1N1N3N92N1NN11N
REL15006 Ion = 1 A/5 A ; 0.01…2 Ion 24…60 Vac/Vdc P1F1B1N0N91N1NN11N
REL15007 Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1B1N0N92N1NN11N
REL15008 Ion = 1 A/5 A ; 0.05…12 Ion 24…60 Vac/ Vdc P1F1B1N3N91N1NN11N
REL15009 Ion = 1 A/5 A ; 0.05…12 Ion 90…240 Vac/250 Vdc P1F1B1N3N92N1NN11N
REL15010 Ion = 1 A/5 A ; 0.01…2 Ion 24…60 Vac/Vdc P1F1A1N0N91N1NN11N
REL15011 Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1A1N0N92N1NN11N
REL15012 Ion = 1 A/5 A ; 0.05…12 Ion 24…60 Vac/ Vdc P1F1A1N3N91N1NN11N
REL15013 Ion = 1 A/5 A ; 0.05…12 Ion 90…240 Vac/250 Vdc P1F1A1N3N92N1NN11N
REL15014 Ion = 1 A/5 A ; 0.01…2 Ion 24…60 Vac/Vdc P1F1E1N0N91N1NN11N
REL15015 Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1E1N0N92N1NN11N
REL15016 Ion = 1 A/5 A ; 0.05…12 Ion 24…60 Vac/Vdc P1F1E1N3N91N1NN11N
REL15017 Ion = 1 A/5 A ; 0.05…12 Ion 90…240 Vac/250 Vdc P1F1E1N3N92N1NN11N
REL15020 Ion = 1 A/5 A ; 0.01…2 Ion 24…60 Vac/Vdc P1F1E110N91N1NN11N
REL15021 Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1E110N92N1NN11N
REL15022 Ion = 1 A/5 A ; 0.05…12 Ion 24…60 Vac/Vdc P1F1E113N91N1NN11N
REL15023 Ion = 1 A/5 A ; 0.05…12 Ion 90…240 Vac/250 Vdc P1F1E113N92N1NN11N
REL15054 Ion = 1 A/5 A ; 0.01…2 Ion 24…60 Vac/Vdc P1F1C1N0N91N1NN12N
REL15055 Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1C1N0N92N1NN12N
REL15056 Ion = 1 A/5 A ; 0.01…2 Ion 24…60 Vac/Vdc P1F1C1N0N91N1NN12N
REL15055 Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1C1N0N92N1NN12N
REL15050 Ion = 1 A/5 A ; 0.01…2 Ion 24…60 Vac/Vdc P1F1T1N0N91N11N12N
REL15051 Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1T1N0N92N11N12N

REL15052 Ion = 1 A/5 A ; 0.01…2 Ion 24…60 Vac/Vdc P1F1T110N91N11N12N
REL15053 Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1T110N92N11N12N
REL15060 Ion = 1 A/5 A ; 0.01…2 Ion 24…60 Vac/Vdc P1F1H110N91N1NN11N
REL15061 Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1H110N92N1NN11N
REL15006C Ion = 1 A/5 A ; 0.01…2 Ion 24…60 Vac/Vdc P1F1B1N0N91N1NN31N
REL15007C Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1B1N0N92N1NN31N
REL15008C Ion = 1 A/5 A ; 0.05…12 Ion 24…60 Vac/Vdc P1F1B1N3N91N1NN31N
REL15009C Ion = 1 A/5 A ; 0.05…12 Ion 90…240 Vac/250 Vdc P1F1B1N3N92N1NN31N
REL15014C Ion = 1 A/5 A ; 0.01…2 Ion 24…60 Vac/Vdc P1F1E1N0N91N1NN31N
REL15015C Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1E1N0N92N1NN31N
REL15016C Ion = 1 A/5 A ; 0.05…12 Ion 24…60 Vac/Vdc P1F1E1N3N91N1NN31N
REL15017C Ion = 1 A/5 A ; 0.05…12 Ion 90…240 Vac/250 Vdc P1F1E1N3N92N1NN31N
REL15060C Ion = 1 A/5 A ; 0.01…2 Ion 24…60 Vac/Vdc P1F1H110N91N1NN31N
REL15061C Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1H110N92N1NN31N
REL15007R Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1B1N0N92N1NN11N
REL15009R Ion = 1 A/5 A ; 0.05…12 Ion 90…240 Vac/250 Vdc P1F1B1N3N92N1NN11N
REL15011R Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1A1N0N92N1NN11N
REL15013R Ion = 1 A/5 A ; 0.05…12 Ion 90…240 Vac/250 Vdc P1F1A1N3N92N1NN11N
REL15021R Ion = 1 A/5 A ; 0.01…2 Ion 90…240 Vac/250 Vdc P1F1E110N92N1NN11N
REL15023R Ion = 1 A/5 A ; 0.05…12 Ion 90…240 Vac/250 Vdc P1F1E113N92N1NN11N

PowerLogic P1V – Voltage and Frequency protection
REL15024 Un = 57…130 Vac 24…240 Vac/250 Vdc P1V1L10N1N2N0NN11N
REL15025 Un = 220…480 Vac 24…240 Vac/250 Vdc P1V1L10N2N2N0NN11N
REL15026 Un = 57…130 Vac 24…60 Vac/dc P1V1N11N1N1N1NN11N
REL15027 Un = 220…480 Vac 24…60 Vac/dc P1V1N11N2N1N1NN11N
REL15028 Un = 57…130 Vac 90…240 Vac/250 Vdc P1V1N11N1N2N1NN11N
REL15029 Un = 220…480 Vac 90…240 Vac/250 Vdc P1V1N11N2N2N1NN11N
REL15030 Un = 57…130 Vac 24…60 Vac/Vdc P1V1A11N1N1N1NN11N
REL15031 Un = 220…480 Vac 24…60 Vac/Vdc P1V1A11N2N1N1NN11N
REL15032 Un = 57…130 Vac 90…240 Vac/250 Vdc P1V1A11N1N2N1NN11N
REL15033 Un = 220…480 Vac 90…240 Vac/250 Vdc P1V1A11N2N2N1NN11N
REL15030C Un = 57…130 Vac 24…60 Vac/Vdc P1V1A11N1N1N1NN31N
REL15031C Un = 220…480 Vac 24…60 Vac/Vdc P1V1A11N2N1N1NN31N
REL15032C Un = 57…130 Vac 90…240 Vac/250 Vdc P1V1A11N1N2N1NN31N
REL15033C Un = 220…480 Vac 90…240 Vac/250 Vdc P1V1A11N2N2N1NN31N
REL15024R Un = 57…130 Vac 24…240 Vac/250 Vdc P1V1L10N1N2N0NN11E
REL15028R Un = 57…130 Vac 90…240 Vac/250 Vdc P1V1L10N1N2N0NN11E
REL15032R Un = 57…130 Vac 90…240 Vac/250 Vdc P1V1A11N1N2N1NN11E

Accessories
REL15039
REL15040
REL15041
REL15042
REL15043

* PowerLogic P3 Protection Relays
PowerLogic P3U20
PowerLogic P3F30
PowerLogic P3L30
PowerLogic P3M30
PowerLogic P3M32
PowerLogic P3T32
PowerLogic P3G30
PowerLogic P3G32
P3G30
P3G32
P3U30
P3T32
P3U30
P3F30
P3L30
P3U30
P3M30
P3M32
REL52812
REL52811
REL52813
REL52814

LPVT
LPCT
EMS59573: LPVT hub connector
EMS59572: Voltage adapter
P7M12025: LPVT transducer
REL51037: LPIT test box

LPCT Test Socket and Plug
REL51089: LPCT Test Socket Essailec (incl. cover)
REL51090: LPCT Test Plug Essailec
REL51092: LPVT Test Socket Essailec (incl. cover)
REL51093: LPVT Test Plug Essailec
LPVT Test Socket and Plug

Core balance CT
59635: CSH120
59636: CSH200
59637: CSH300

REL52801
REL52802
REL52803
REL52804
REL52805
REL52806
REL52839
REL52840
REL52807
REL52808
REL52809
REL52810
REL52829
REL52828

REL52836: P3UWAF Wall mounted adapter
REL52842:P3XPAF Wall mounted adapter
REL52839 and REL52840: Arc Flash cables
REL52833: P3UPSC Panel seal cover
REL52837: P3UPAV200 Adapter plate
REL52844: P3UPAVS40 Adapter plate

REL52001 P3U30-5AAA3BCAA
REL52002 P3U30-5AAA3BBAA
REL52003 P3U30-5AAA1BCAA
REL52004 P3U30-5AAA2BCAA
REL52005 P3U30-5AAA1BBAA
REL52006 P3U30-5ABA1BBAA
REL52007 P3U30-5AAA1BDAA
REL52008 P3U30-6AAA2BCAA
REL52009 P3U30-5ABA1BCAA
REL52010 P3U30-5AAA2BDAA
REL52011 P3U20-5ABA1ACAA
REL52012 P3U30-5AAA2BBAA
REL52013 P3U20-5AAA1ACAA
REL52014 P3U30-5ABA1BDAA
REL52015 P3U20-6AAA2ACAA
REL52016 P3U30-6AAA2BBAA
REL52017 P3U30-6AAA3BCAA
REL52018 P3U20-5AAA2ACAA
REL52019 P3U30-5AAA1BFAA
REL52020 P3U30-6ABA1BBAA
REL52021 P3U30-6AAA2BDAA
REL52022 P3U30-6AAA1BCAA
REL52025 P3U30-5BAA2BCAA
REL52032 P3U20-5AAA1ABAA
REL52033 P3U20-5AAA1ADAA
REL52034 P3U20-6AAA1ABAA
REL52035 P3U20-6AAA1ACAA
REL52036 P3U20-6AAA1ADAA
REL52037 P3U20-5AAA2ABAA
REL52038 P3U20-5AAA2ADAA
REL52039 P3U20-6AAA2ABAA
REL52040 P3U20-6AAA2ADAA
REL52041 P3U20-5AAA3ABAA
REL52042 P3U20-5AAA3ACAA
REL52044 P3U20-6AAA3ABAA
REL52045 P3U20-6AAA3ACAA
REL52047 P3U30-6AAA1BBAA
REL52048 P3U30-6AAA1BDAA
REL52049 P3U30-5AAA3BDAA
REL52050 P3U30-6AAA3BBAA
REL52051 P3U30-6AAA3BDAA
REL52073 P3U30-7AAA1CDAA
REL52075 P3U30-7AAA2CCAA
REL52077 P3U30-7AAA3CCAA
REL52078 P3U30-7AAA1CBAA
REL52093 P3U30-6CAA2BCAA
REL52094 P3U30-6CAA1BBAA
REL52095 P3U30-6CAA2BDAA
REL52096 P3U30-5CAA1BCAA
REL52097 P3U30-6CAA3BCAA
REL52201 P3U30-6ABA1BCAA
REL52203 P3U20-6AAA2AHAA
REL52210 P3U30-6ABA1BDAA
REL53000 P3U30-6AAA1BCAB
REL53002 P3U30-6AAA2BEAB
REL53003 P3U30-6AAA1BEAB
REL53090 P3U30-6ABA1BDAB
REL53091 P3U30-6ABA1BCAB
REL53092 P3U30-6ABA1BBAB
REL53102 P3U30-6AAA2BDAB
REL53131 P3U30-6AAA2BHAB
REL53132 P3U30-6ABA1BHAB
REL53144 P3U30-6AAA1BDAB
REL53152 P3U30-6AAA2BGAB
REL53154 P3U30-6ABA1BEAB
REL53155 P3U30-6ABA1BGAB
REL53157 P3U20-6CAA3AHAA
REL53158 P3U30-6CAA3BHAA
REL53159 P3U30-8CAA3CCAA
REL53160 P3U30-6CAA2BHAA

Accessories
REL52801
VA1DA-20
REL52802
VA1DA-20S-HF
REL52803
VA1DA-20S
REL52804
VA1DA-6
REL52805
VA1DA-6S-HF
REL52806
VA1DA-6S
REL52807
VA1EH-20
REL52808
VA1EH-20S
REL52809
VA1EH-6
REL52810
VA1EH-6S
REL52839
VA1DA-6W
REL52840
VA1DA-20W
REL52851
VA2DV-3-SE
REL52852
VA2DV-6-SE
REL52811
VIO12AASE
REL52812
VIO12ABSE
REL52813
VIO12ACSE
REL52814
VIO12ADSE
REL52815
VPA3CGSE
REL52820
VSE002
REL52816
VSE001-GGSE
REL52817
VSE001-GPSE
REL52818
VSE001-PGSE
REL52819
VSE001-PPSE
REL52842
ARC SLM-1
REL52843
ARC SLM-5
REL52844
ARC SLM-10
REL52845
ARC SLM-15
REL52846
ARC SLM-20
REL52847
ARC SLM-25
REL52848
ARC SLM-30
REL52849
ARC SLM-40
REL52853
ARC SLM-50

REL52822 USB cable
REL52828 VYX001
REL52829 VYX002
REL52831 VYX301
REL52832 VYX695
REL52823 VX067
REL52824 VX072
REL52838 VX086
REL52842 P3XPAF
REL52834 VYX860
REL52833 P3UPSC
REL52825 VX082
REL52826 VX083
REL52827 VX084
REL52836 P3UWAF
REL52837 P3UPAV200
REL52844 P3UPAVS40

Sensors
59635
59636
59637
EMS59572
EMS59573
03813519N0
03818034N0
03811060N0
03811061N0
03816498N0
03816686N0
03816695N0
LPVT36GC
LPVT17GNKT
LPVT24GNKT
LPVT36GNKT
LPVT17GNE
LPVT24GNE
LPVT36GNE

Sensors
LPVT17A
LPVT17A
LPVT24A
REL51037
REL51089
REL51090
REL51092
REL51093
P7M12025
REL51095

* PowerLogic P5 Protection and Control Relays
P5V20
P5U20
P5U20
P5F30
P5M30
P5T30
P5L30
PowerLogic P5U20 – Universal Application
PowerLogic P5U20 – Universal Application with LPCT/LPVT
PowerLogic P5V20 – Voltage Application
PowerLogic P5F30 – Feeder Application
PowerLogic P5L30 – Line Differential Application
PowerLogic P5M30 – Motor Application
PowerLogic P5T30 – Transformer Differential Application

REL51049: Combined module Ethernet HSR/PRP FO and RS485 serial line
REL51048: Combined module Ethernet HSR/PRP TP and RS485 serial line
REL51038: Ethernet TP module
REL51039: Ethernet FO module
REL51042: Second Ethernet TP module
REL51097: Second Ethernet FO module
REL51040: Fiber optic serial line module
REL51036: RS485 serial line module
REL51043: InterRelay FO single-mode module up to 40 km
REL51053: InterRelay FO multi-mode module up to 2 km
REL51034: Extension module
REL51044: Extension module with wireless communication
EMS59440: Thermal sensor TH110 – 3 pcs
EMS59443: Temperature and humidity sensor CL110 – 2 pcs
REL51045: IRIG-B module
59641: Temperature sensor module
REL70071: Analog I/O (CLIO) Module
EMS59573: LPVT hub connector
EMS59572 / EMS59574: Voltage adapter

P7M12025: LPVT transducer
REL51037: LPIT test box
REL51089: LPCT Test Socket Essailec (incl. cover)
REL51090: LPCT Test Plug Essailec
REL51092: LPVT Test Socket Essailec (incl. cover)
REL51093: LPVT Test Plug Essailec

Core balance CT
59635:CSH120
59636:CSH200
59637:CSH300

Interposing CT 59634: CSH30

Arc-flash Sensors
REL52801
REL52802
REL52803
REL52804
REL52805
REL52806
REL52807
REL52808
REL52809
REL52810
Mounting Accessories
REL51020
REL51019
REL51018
REL51021
REL51032 : 20TE Flush mounting accessory
REL51052 : 30TE Flush mounting accessory

REL50301 P5U20-AABA-BAAAA-BAEA
REL50302 P5U20-AABA-CAAAA-BAEA
REL50303 P5U20-AABB-BAAAA-BAEA
REL50304 P5U20-AABB-CAAAA-BAEA
REL50331 P5U20-AABA-BABAH-BAEA
REL50333 P5U20-AABB-BABAH-BAEA
REL50334 P5U20-AABB-CABAH-BAEA
REL50305 P5V20-AABA-DAAAA-BAEA
REL50340 P5V20-AABB-DABAH-BAEA

REL50402 P5F30-AACB-HAAAA-BAEA
REL50404 P5F30-BACB-GAAAA-BAEA
REL50405 P5F30-BACB-HAAAA-BAEA
REL50451 P5F30-AACB-GABAH-BAEA
REL50452 P5F30-AACB-HABAH-BAEA
REL50453 P5F30-BACB-GABAH-BAEA
REL50454 P5F30-BACB-HABAH-BAEA
REL50406 P5F30-BACB-IAAAA-BAEA
REL50411 P5M30-BACB-HAAAA-BAEA
REL50456 P5M30-AACB-HABAH-BAEA
REL50457 P5M30-BACB-GABAH-BAEA
REL50458 P5M30-BACB-HABAH-BAEA
REL50412 P5M30-BACB-IAAAA-BAEA

REL50493 P5T30-AADB-JAAAA-BAEA
REL50495 P5T30-BADD-JAAAA-BAEA
REL50497 P5T30-CBDD-JABAH-BAEA
REL50494 P5T30-AACB-JAAAA-BAEA
REL50496 P5T30-BACD-JAAAA-BAEA
REL50498 P5T30-CBCD-JABAH-BAEA
REL50507 P5L30-AADD-LEAAA-BAEA
REL50509 P5L30-AADB-MEAAA-BAEA
REL50511 P5L30-AADD-LDAAA-BAEA
REL50513 P5L30-AADB-MDAAA-BAEA
REL50508 P5L30-AACD-LEAAA-BAEA
REL50510 P5L30-AACB-MEAAA-BAEA
REL50512 P5L30-AACD-LDAAA-BAEA
REL50514 P5L30-AACB-MDAAA-BAEA

External modules
REL51038
REL51039
REL51049
REL51048
REL51042
REL51097*
REL51043
REL51053
REL51036
REL51040
REL51034
REL51044
VW3A8306RC
LV434211
REL51045
REL70071
59641
59660
59661
59662
59634
59635
59636
59637
59700
EMS59572
EMS59572
EMS59573
REL51037
REL51089
REL51090
REL51092
REL51093
P7M12025
REL51095

REL52801
REL52802
REL52803
REL52804
REL52805
REL52806
REL52807
REL52808
REL52809
REL52810
REL51032
REL51052
REL51021
REL51018
REL51019
REL51020
REL51077
REL51078
REL51079
REL51088
REL70063
REL70064
REL70067

* PowerLogic P7 Protection and Control Devices
REL70062: Ethernet SFP Module 100/1000 Mbps RJ45
REL70063: Ethernet SFP Module 100 Mbps multimode
REL70064: Ethernet SFP Module 100 Mbps Singlemode
REL70067: Ethernet SFP Module 1000 Mbps Singlemode
PSU ring-type terminal block (reference REL70153)
REL51045 : IRIG-B module
59641 : Temperature Sensor Module
REL70071 : CLIO module

Cables and Cords
59660 0.6 m remote module connection cord
59661 2 m remote module connection cord
59662 4 m remote module connection cord
59700 USB cord for PC connection

DHMI module (reference REL70124)
PSU ring-type terminal block (reference REL70153)

Motor Application
REL72500 P7M41-1CR5NNMMNNNNNNNNN-TLB
P7 Motor Advanced level 5CT 4VT 24BI 20BO 24-34V Eth RJ45
REL72501 P7M41-1CR5NNMMNNNNNNNNN-TMB
P7 Motor Advanced level 5CT 4VT 24BI 20BO 48-125V Eth RJ45
REL72502 P7M41-1CR5NNMMNNNNNNNNN-THB
P7 Motor Advanced level 5CT 4VT 24BI-20BO 110-250V Eth RJ45
REL72503 P7M41-1CR5MMMMNNNNNNNNN-TLB
P7 Motor Advanced level 5CT 4VT 40BI 32BO 24-34V Eth RJ45
REL72504 P7M41-1CR5MMMMNNNNNNNNN-TMB
P7 Motor Advanced level 5CT 4VT 40BI 32BO 48-125V Eth RJ45
REL72505 P7M41-1CR5MMMMNNNNNNNNN-THB
P7 Motor Advanced level 5CT 4VT 40BI 32BO 110-250V Eth RJ45
REL72506 P7M41-1CR5R6MMNNNNNNNNN-TLB
P7 Motor Advanced level 11CT 7VT 24BI 20BO 24-34V Eth RJ45
REL72507 P7M41-1CR5R6MMNNNNNNNNN-TMB
P7 Motor Advanced level 11CT 7VT 24BI 20BO 48-125V Eth RJ45
REL72508 P7M41-1CR5R6MMNNNNNNNNN-THB
P7 Motor Advanced level 11CT 7VT 24BI 20BO 110-250V Eth RJ45

Generator Application
REL73500 P7G41-1CR5NNMMNNNNNNNNN-TLB
P7 Generator Advanced level 5CT 4VT 24BI 20BO 24-34V Eth RJ45
REL73501 P7G41-1CR5NNMMNNNNNNNNN-TMB
P7 Generator Advanced level 5CT 4VT 24BI 20BO 48-125V Eth RJ45
REL73502 P7G41-1CR5NNMMNNNNNNNNN-THB
P7 Generator Advanced level 5CT 4VT 24BI 20BO 110-250V Eth RJ45
REL73503 P7G41-1CR5MMMMNNNNNNNNN-TLB
P7 Generator Advanced level 5CT 4VT 40BI 32BO 24-34V Eth RJ45
REL73504 P7G41-1CR5MMMMNNNNNNNNN-TMB
P7 Generator Advanced level 5CT 4VT 40BI 32BO 48-125V Eth RJ45
REL73505 P7G41-1CR5MMMMNNNNNNNNN-THB
P7 Generator Advanced level 5CT 4VT 40BI 32BO 110-250V Eth RJ45
REL73506 P7G41-1CR5R6MMNNNNNNNNN-TLB
P7 Generator Advanced level 11CT 7VT 24BI 20BO 24-34V Eth RJ45
REL73507 P7G41-1CR5R6MMNNNNNNNNN-TMB
P7 Generator Advanced level 11CT 7VT 24BI 20BO 48-125V Eth RJ45
REL73508 P7G41-1CR5R6MMNNNNNNNNN-THB
P7 Generator Advanced level 11CT 7VT 24BI 20BO 110-250V Eth RJ45

Feeder Application
REL71500 P7F41-1CR5NNMMNNNNNNNNN-TLB
P7 Feeder Advanced level 5CT 4VT 24BI 20BO 24-34V Eth RJ45
REL71501 P7F41-1CR5NNMMNNNNNNNNN-TMB
P7 Feeder Advanced level 5CT 4VT 24BI 20BO 48-125V Eth RJ45
REL71502 P7F41-1CR5NNMMNNNNNNNNN-THB
P7 Feeder Advanced level 5CT 4VT 24BI 20BO 110-250V Eth RJ45
REL71503 P7F41-1CR5MMMMNNNNNNNNN-TLB
P7 Feeder Advanced level 5CT 4VT 40BI 32BO 24-34V Eth RJ45
REL71504 P7F41-1CR5MMMMNNNNNNNNN-TMB
P7 Feeder Advanced level 5CT 4VT 40BI 32BO 48-125V Eth RJ45
REL71505 P7F41-1CR5MMMMNNNNNNNNN-THB
P7 Feeder Advanced level 5CT 4VT 40BI 32BO 110-250V Eth RJ45

Transformer Application
REL76500 P7T41-1CR6NNMMNNNNNNNNN-TLB
P7 Transformer Advanced level 6CT 3VT 24BI 20BO 24-34V Eth RJ45
REL76501 P7T41-1CR6NNMMNNNNNNNNN-TMB
P7 Transformer Advanced level 6CT 3VT 24BI 20BO 48-125V Eth RJ45
REL76502 P7T41-1CR6NNMMNNNNNNNNN-THB
P7 Transformer Advanced level 6CT 3VT 24BI 20BO 110-250V Eth RJ45
REL76503 P7T41-1CR6MMMMNNNNNNNNN-TLB
P7 Transformer Advanced level 6CT 3VT 40BI 32BO 24-34V Eth RJ45
REL76504 P7T41-1CR6MMMMNNNNNNNNN-TMB
P7 Transformer Advanced level 6CT 3VT 40BI 32BO 48-125V Eth RJ45
REL76505 P7T41-1CR6MMMMNNNNNNNNN-THB
P7 Transformer Advanced level 6CT 3VT 40BI 32BO 110-250V Eth RJ45
REL76506 P7T41-1CR6R6MMNNNNNNNNN-TLB
P7 Transformer Advanced level 12CT 6VT 24BI 20BO 24-34V Eth RJ45
REL76507 P7T41-1CR6R6MMNNNNNNNNN-TMB
P7 Transformer Advanced level 12CT 6VT 24BI 20BO 48-125V Eth RJ45
REL76508 P7T41-1CR6R6MMNNNNNNNNN-THB
P7 Transformer Advanced level 12CT 6VT 24BI 20BO 110-250V Eth RJ45

Stand – Alone Merging Unit Application
REL79200 P7S40-0CR5NNNNNNNNNNNNN-TLB
PowerLogic P7 SAMU Essential 5CT 4VT 8BI 8BO 24-34V Eth RJ45
REL79201 P7S40-0CR5NNNNNNNNNNNNN-TMB
PowerLogic P7 SAMU Essential 5CT 4VT 8BI 8BO 48-125V Eth RJ45
REL79202 P7S40-0CR5NNNNNNNNNNNNN-THB
PowerLogic P7 SAMU Essential 5CT 4VT 8BI 8BO 110-250V Eth RJ45
REL79203 P7S41-0CR5NNMMNNNNNNNNN-TLB
PowerLogic P7 SAMU Advanced 5CT 4VT 24BI 20BO 24-34V Eth RJ45
REL79204 P7S41-0CR5NNMMNNNNNNNNN-TMB
PowerLogic P7 SAMU Advanced 5CT 4VT 24BI 20BO 48-125V Eth RJ45
REL79205 P7S41-0CR5NNMMNNNNNNNNN-THB
PowerLogic P7 SAMU Advanced 5CT 4VT 24BI 20BO 110-250V Eth RJ45
REL79206 P7S41-0CR5R5MMNNNNNNNNN-TLB
PowerLogic P7 SAMU Advanced 10CT 8VT 24BI 20BO 24-34V Eth RJ45
REL79207 P7S41-0CR5R5MMNNNNNNNNN-TMB
PowerLogic P7 SAMU Advanced 10CT 8VT 24BI 20BO 48-125V Eth RJ45
REL79208 P7S41-0CR5R5MMNNNNNNNNN-THB
PowerLogic P7 SAMU Advanced 10CT 8VT 24BI 20BO 110-250V Eth RJ45
REL79209 P7S41-0CR6R6MMNNNNNNNNN-TLB
PowerLogic P7 SAMU Advanced flexibility 12CT 6VT 24BI 20BO 24-34V Eth RJ45
REL79210 P7S41-0CR6R6MMNNNNNNNNN-TMB
PowerLogic P7 SAMU Advanced flexibility 12CT 6VT 24BI 20BO 48-125V Eth RJ45
REL79212 P7S41-1CR6R6MMNNNNNNNNN-TLB
PowerLogic P7 SAMU Advanced flexibility12CT 6VT 24BI 20BO 24-34V Eth RJ45
REL79213 P7S41-1CR6R6MMNNNNNNNNN-TMB
PowerLogic P7 SAMU Advanced flexibility 12CT 6VT 24BI 20BO 48-125V Eth RJ45
REL79214 P7S41-1CR6R6MMNNNNNNNNN-THB
PowerLogic P7 SAMU Advanced flexibility 12CT 6VT 24BI 20BO 110-250V Eth RJ45
REL79215 P7S41-1CR5NMMMNNNNNNNNN-TLB
PowerLogic P7 SAMU Advanced flexibility 5CT 4VT 32BI 26BO 24-34V Eth RJ45
REL79216 P7S41-1CR5NMMMNNNNNNNNN-TMB
PowerLogic P7 SAMU Advanced flexibility 5CT 4VT 32BI 26BO 48-125V Eth RJ45
REL79217 P7S41-1CR5NMMMNNNNNNNNN-THB
PowerLogic P7 SAMU Advanced flexibility 5CT 4VT 32BI 26BO 110-250V Eth RJ45

Bay Controller Application
REL79500 P7C41-1CR5NNMMNNNNNNNNN-TLB
PowerLogic P7 Bay Control Advanced 5CT 4VT 24BI 20BO 24-34V Eth RJ45
REL79501 P7C41-1CR5NNMMNNNNNNNNN-TMB
PowerLogic P7 Bay Control Advanced 5CT 4VT 24BI 20BO 48-125V Eth RJ45
REL79502 P7C41-1CR5NNMMNNNNNNNNN-THB
PowerLogic P7 Bay Control Advanced 5CT 4VT 24BI 20BO 110-250V Eth RJ45
REL79503 P7C41-1CR5IIMMNNNNNNNNN-TLB
PowerLogic P7 Bay Control Advanced 5CT 4VT 56BI 20BO 24-34V Eth RJ45
REL79504 P7C41-1CR5IIMMNNNNNNNNN-TMB
PowerLogic P7 Bay Control Advanced 5CT 4VT 56BI 20BO 48-125V Eth RJ45
REL79505 P7C41-1CR5IIMMNNNNNNNNN-THB
PowerLogic P7 Bay Control Advanced 5CT 4VT 56BI 20BO 110-250V Eth RJ45
REL79506 P7C41-1CNNIIMMNNNNNNNNN-TLB
PowerLogic P7 Bay Control Advanced 0CT 0VT 56BI 20BO 24-34V Eth RJ45
REL79507 P7C41-1CNNIIMMNNNNNNNNN-TMB
PowerLogic P7 Bay Control Advanced 0CT 0T 56BI 20BO 48-125V Eth RJ45
REL79508 P7C41-1CNNIIMMNNNNNNNNN-THB
PowerLogic P7 Bay Control Advanced 0CT 0VT 56BI 20BO 110-250V Eth RJ45
REL79509 P7C41-1CIIIIMMNNNNNNNNN-TLB
PowerLogic P7 Bay Control Advanced 0CT 0VT 88BI 20BO 24-34V Eth RJ45
REL79510 P7C41-1CIIIIMMNNNNNNNNN-TMB
PowerLogic P7 Bay Control Advanced 0CT 0VT 88BI 20BO 48-125V Eth RJ45
REL79511 P7C41-1CIIIIMMNNNNNNNNN-TMB
PowerLogic P7 Bay Control Advanced 0CT 0VT 88BI 20BO 110-250V Eth RJ45

Line Differential Application
REL75500 P7L41-1CR5NNMMNNNNNNNNN-TLB
PowerLogic P7 Line Differential Advanced 5CT 4VT 24BI 20BO 24-34V Eth RJ45
REL75501 P7L41-1CR5NNMMNNNNNNNNN-TMB
PowerLogic P7 Line Differential Advanced 5CT 4VT 24BI 20BO 48-125V Eth RJ45
REL75502 P7L41-1CR5NNMMNNNNNNNNN-THB
PowerLogic P7 Line Differential Advanced 5CT 4VT 24BI 20BO 110-250V Eth RJ45
REL75503 P7L41-1CR5MMMMNNNNNNNNN-TLB
PowerLogic P7 Line Differential Advanced 5CT 4VT 40BI 32BO 24-34V Eth RJ45
REL75504 P7L41-1CR5MMMMNNNNNNNNN-TMB
PowerLogic P7 Line Differential Advanced 5CT 4VT 40BI 32BO 48-125V Eth RJ45
REL75505 P7L41-1CR5MMMMNNNNNNNNN-THB
PowerLogic P7 Line Differential Advanced 5CT 4VT 40BI 32BO 110-250V Eth RJ45

Busbar Application
REL77500 P7B41-1CR6R6MMNNNNNNNNN-TLB
PowerLogic P7 Busbar Advanced 12CT 6VT 24BI 20BO 24-34V Eth RJ45
REL77501 P7B41-1CR6R6MMNNNNNNNNN-TMB
PowerLogic P7 Busbar Advanced 12CT 6VT 24BI 20BO 48-125V Eth RJ45
REL77502 P7B41-1CR6R6MMNNNNNNNNN-THB
PowerLogic P7 Busbar Advanced 12CT 6VT 24BI 20BO 110-250V Eth RJ45

Spare parts
REL70130 P7 5 CT+4 VT Ring terminal module
REL70131 P7 6 CT+3 VT Ring terminal module
REL70132 P7 5 CT+4 VT Pin terminal module
REL70133 P7 6 CT+3 VT Pin terminal module
REL70142 Mixed card – 8DI/6DO
REL70143 Mixed card – 8DI/6DO (PSU auxiliary)
REL70144 Input card – 16I
REL70146 Direct motor control board 7DI/7DO
REL70150 24-32 Vdc supply 2DO + WD
REL70151 48-110 Vdc supply 2DO + WD
REL70152 110-250 Vdc/100-240 Vac supply 2DO + WD
REL70162 SFP ETH module RJ45 100/1000 Mbps, 10pcs in a box
REL70163 SFP ETH module Multimode 100 Mbps, 10pcs in a box
REL70164 SFP ETH module Singlemode 100 Mbps, 10pcs in a box
REL70167 SFP ETH module Singlemode 100/1000 Mbps, 10pcs in a box

… …
